Honeywell Home

6-inch Round Fresh Air Damper ; EARD6TZ

6-inch Round Fresh Air Damper
View specifications
$0.00
SKU EARD6TZ

Specifications

Brand Honeywell Home
Product Series EARD Series
Country of Origin Mexico
Part Number EARD6TZ/U
UPC 85267690423
Damper Type Backdraft Damper
Material Galvanized Steel
Supply Voltage 24V
Installation Type On Duct
Shape Round
Color Silver
Additional Specifications For use with Honeywell Home Ventilation Systems
Product Diameter 6 "
Shipping Length/Depth 6.25 "
Shipping Width 11.25 "
Shipping Height 8.125 "
Shipping Weight 3.3 lb
description

The EARD is a round damper with a 24 Vac powered-open/spring-closed motor. It is used for fresh air intake for ventilation or for combustion makeup air.

  • Adjustable damper position range stops.
  • Single-blade damper
  • Galvanized steel
  • Quiet operation
  • Can be field-converted to power closed/spring return open damper
  • Blade closes off tightly against gasket for minimal leakage
  • Male (crimped) and female (uncrimped) ends to connect to any rigid or flexible round duct
