HH8 Side-Discharge Heat Pump, 18 SEER2, 5 Tons, R-454B, 208/230V

HH8 Side-Discharge Heat Pump, 18 SEER2, 5 Tons, R-454B, 208/230V
$0.00
SKU HH860E2S11
Brand JCI
Part Number HH860E2S11
Cooling Capacity 60000 BTU/hr
SEER Rating 18 SEER2
Energy Star No
Supply Voltage 208V, 230V
Phase Single Phase
Hertz 50/60Hz
Maximum Fuse Size (MOP) 45 A
Tons 5 T
Compressor Type Rotary
Refrigerant (ASHRAE) R-454B
Shipping Length/Depth 38.4 "
Shipping Width 13 "
Shipping Height 57.5 "
Shipping Weight 258 lb

These cutting-edge heat pumps feature the next generation of low global warming potential refrigerant R-454B, making them environmentally friendly and energy efficient. With an impressive 18+ SEER2 rating, the HH8 is designed to deliver exceptional performance and savings. Featuring a state-of-the-art inverter driven compressor, the HH8 heat pumps offer precise temperature control to meet each customer's comfort needs.

With the help of a conventional heat pump thermostat, the system automatically adjusts its capacity and airflow, ensuring optimal comfort while keeping energy bills in check. Not only does the HH8 work seamlessly with York variable speed or standard ECM indoor air handling equipment, but it is also compatible with York Furnaces and can be easily integrated with any third-party indoor units. This versatility provides consumers and dealers with a wide range of installation options.

In addition, the HH8 incorporates advanced self-diagnostic features in both the main control and inverter control systems. This allows for quick and efficient troubleshooting, should the need for service arise. HH8 is the ultimate choice for superior comfort, energy savings, and system reliability.
